Specification
| Steel framework(Q235B,Q345B) | 1.Steel beam
2.Steel column
3.Bracing
4.H cross-section steel,box cross-section steel,round pipe,round steel,L steel,etc. |
| Wall and roof | 1.Single steel sheet 0.36mm-0.6mm thick
2.Sandwich panel with EP,PU,glass wool and rock wool(50-120mm) |
| Door | 1.Roller door
2.Sliding door and sidewall door
3.Steel sheet, sandwich panel or aluminum-alloy.
4.According to your requirements |
| Window | 1.Sliding window
2.Plastic-steel frame or aluminum frame
3.According to your requirements |
| Gutter | 1.Aluminum-zinc steel sheet
2.Stainless sheet |
| Downpipe | 1.PVC
2.Stainless pipe |
| Skylight panel | FRP,1.5mm,2.0mm,2.5mm,according to your requirements |
| Ventilation | 1.Turbine vent
2.Ridge vent
3.According to your requirements |
| Other materials | Self-screwing tapping,bolt,nut etc. |
Steel structure building is one kind of product which can be designed as per every peoples' different need.
So, if you found that follows example pictures are not as same as your request, even it is very different.
Do not worry.No matter which kind of building you need, bigger, smaller or multi-storey, just offer me the data or drawing of building what you need.
We will make the exact design, quotation and rendering for you as soon as we can.
(our factory have more than 30 years experience in steel structure and more than 20 years in steel structure building, and our chief engineer have about 20 years experience in building.)
Materials:
1. The main frame (columns and beams) is made of welded H-style steel.
2. The columns are connected with the foundation by pre-embedding anchor bolt.
3. The beams and columns, beams and beams are connected with high intensity bolts.
4. The envelope construction net is made of cold form C-style purlins.
5. The wall and roof are made of color steel board or color steel sandwich panels, which are connected with the purlin by Self-tapping nails.
6. Doors and windows can be designed at anywhere which can be made into normal type, sliding type or roll up type with material of PVC, metal, alloy aluminum, sandwich panel and so on.
